Ricoh SP 110 SU - Page 32

1. Lift the exposure glass cover.
2. Place the original face down on the exposure glass. The original should be aligned to the
rear left corner.
CXP047
3. Lower the exposure glass cover.
Scanning thick originals
1. Lift the exposure glass cover.
2. Pull up the exposure glass cover and remove it.
CXP009
3. Place the original face down on the exposure glass. The original should be aligned to the
rear left corner.
4. Lower the exposure glass cover.
2. Loading Paper
30
