○ or react per the setting of ‘External LED’.
● The Normal Operating Mode Indicator is replaced by a red background white
‘OTP’ Icon.
Notes:
- Disabled by setting to 0.
- Should be set to a higher value than the ambient temperature for proper operation.
- This setting does NOT affect the RD60xx cooling fan.
(Which will turn on automatically when the internal sensor reaches 40°C.)
- There is a pre-set, 80°C, non-changeable OTP for the internal sensor.
- The external temperature probe CAN be used in conjunction with this setting to monitor
the Primary Power Supply temperature for overheating, if the user wishes to mount the
sensor as such.
- The ‘OTP (EXT)’ setting is semi-independent from the ‘CutOff temp.’ setting used for
battery charging.
- ‘OTP (EXT)’ will trigger Protection Mode during all modes of operation.
- ‘CutOff temp.’ only triggers Protection Mode during charging operations.
- IF ‘CutOff temp’ is enabled:
This value, ‘OTP (EXT)’, should be set to a higher value than the ‘CutOff
temp’ to ensure proper operation during charging cycles.
OVP (Over Voltage Protection)
Can only be enabled by Panel buttons (“SHIFT” + “V-SET”)
IF the Voltage reaches, or exceeds, the set value:
● Unit will enter Protection Mode.
● The output will immediately turn OFF.
○ (versus the RD60xx unit adjusting its output to maintain the ‘V-Set’ value.)
● The “ON/OFF” Button will turn off its illumination,
○ or react per the setting of ‘External LED’.
● The Voltage measurement value will be changed to the ‘OVP’ display colour.
○ See ‘Colours Group’ Detailed Explanation
● The Normal Operating Mode Indicator is replaced by a red background white
‘OVP’ Icon.
Notes:
- Disabled by setting to 0.
- When Setting, “SHIFT” button will be illuminated to visually distinguish an ‘OVP’ input
from a ‘V-SET’ input..
OxP Beep
