Update Rate
➥Display
Regarding measured values, Voltage, Current, Power, Etc.
LOW Average value of the last 6 measurements
MEDIUM Average value of the last 3 measurements
HIGH Value of most recent measurement only
Options DO NOT affect measurement accuracy
Options available to smooth measurement Jitter, for readability only.
USB Interface
➥Communication
Selectable Options: OFF / 9600 / 19200 / 38400 / 57600 / 115200
Selects the Baud Rate for use with the Front Panel Micro-USB connector.
When enabled, a USB icon will be displayed at the top of the screen:
UVP (Under Voltage Protection)
➥Power Settings or Quick Setting Menu (“SHIFT” + “▼”)
Value Minimum allowable output Voltage, during normal operation
IF the Voltage falls below the set value:
● Unit will enter Protection Mode.
● The output will immediately turn OFF.
● The “ON/OFF” button will turn off its illumination,
○ or react per the setting of ‘External LED’.
● The Normal Operating Mode indicator is replaced by a red background with a
white ‘UVP’ Icon.
Notes:
- Disabled by setting to 0.
- Protection is not enabled until the Voltage has stopped rising for at least 500ms.
- The PC Software and Smartphone App from Ruideng DO NOT Recognize this error.
IF the RD60xx enters Protection mode due to UVP:
Connected (Riden) Software, using any interface (USB, UART), will report
an ‘OVP’ Error.
