RIDGID JP06101 - Page 39

39
Repair Parts
Parts List for RIDGID 6-1/8" Jointer/Planer
Model No. JP06101
RIDGID parts are available on-line at www.ridgidparts.com
Figure 2
Always order by Part Number - Not by Key Number
* Standard hardware item, may be purchased locally
Key
No.
Part No. Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
828689
805563-6
828400
828517
828518
828524
828522
805467-11
829507
828516
118645
828712
805467-6
805482
828447
Holder Fence
* Washer .515 x 1-1/8 x 3/32
Knob Fence
Sleeve Fence
Nut Tee Fence
Plate Stop
Bolt Shoulder 9mm x 19mm
* Screw Hex Hd 5/16-18 x 1-3/4
Plate Fence Pivot
Screw Pivot
Nut Hex Jam 3/8-16
Knob Fence Tilt
* Screw Hex Hd 5/16-18 x 1
* Nut Hex Jam 5/16-18
Stud Pivot
Key
No.
Part No. Description
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
813640
829506
805297-8
828520
828525
828521
828519
805485
829508
828526
805551-2
809491-5
828401
828529
805567-6
805467
* Nut Hex Jam 1/2-20
Fence
* Screw Flat Hd Soc 5/16-18 x 1-1/2
Nut Handle
Bolt Shoulder 10 x 6
Nut Pivot
Stop Fence
* Nut Hex Jam 7/16-14
Shaft Lock
Collar Lock
* Washer Flat 1/4 x 1/2 x 1/16
* Screw Pan Cr 1/4-20 x 1/2
Handle Asm
Bracket Fence
Washer .63 I.D. x 1-3/4 x 5/32
* Screw Hex Hd 5/16-18 x 1-1/4
