RIDGID JP06101 - Page 41

41
Repair Parts
Parts List for RIDGID 6-1/8" Jointer/Planer
Model No. JP06101
RIDGID parts are available on-line at www.ridgidparts.com
Figure 3
Always order by Part Number - Not by Key Number
* Standard hardware item, may be purchased locally
Key
No.
Part No. Description
1
2
3
4
5
6
7
8
828577
826658
828563
828565
TH260021
827642-1
826817-1
828562
Guard Pulley
Screw Pan Cr Serr 3/16-24 x 3/8
Panel Rear
Panel Asm Right (Includes Key 5)
Plate
Bolt Rd Hd Sh Neck 5/16-18 x 1/2
Nut Hex Flange 5/16-18
Panel Asm Front
Key
No.
Part No. Description
9
10
11
12
13
14
15
16
17
18
19
118615
820296-3
803835-3
828561
828411
826525
828566
828412
HN030900
HE011200
HB040903
* Nut Hex 3/8-16
Washer 10mm I.D.
Foot Leveling 3/8
Panel Asm Left
Chute Dust
Screw Wing
Bracket Motor
Screw Hex Ser Fl 3/8-16 x 3/4
Strain Relief
Flat Washer 5.1 x 11.2 x 1.0T
Screw 3/16-24 x 1/4 in. Pan Hd.
