17
OPERATION
RINSING WITH THE PRESSURE WASHER
Turn off the pressure washer and shut off the water
supply. Pull trigger to release water pressure.
Engage the lock out on the trigger handle by pushing up
on the lock out until it clicks into the slot.
Remove the nozzle by placing hand over nozzle then
pulling back the quick-connect collar.
Select the right nozzle for the job:
• Use medium pressure nozzle (green) for items such as
a car or boat.
• Use higher pressure nozzle for jobs such as stripping
paint and degreasing the driveway. When using these
nozzles, test a small area first to avoid surface damage.
Start at the top of the area to be rinsed and work down,
overlapping the strokes.
MOVING THE PRESSURE WASHER
See Figure 22.
NOTE: Never lift or carry this product using the moving
handle.
Raise the handle.
Turn the pressure washer off.
Tilt the machine toward you until it balances on the wheels
then roll the machine to the desired position.
Fig. 22
TO MOVE THE MACHINE
