CONNECTION OF CBM

Follow the table below for the correct jumper configuration of the terminal blocks, depending on the power connection required.

CBM default configuration

(three phase input, with the bypass commoned with PH1)

CBM Single phase input, with a common bypass

CBM three phase input with a separated bypass line CBM Single phase input, with a separated bypass line

Table 23

Jumpers (for more details about their installation or removal, refer to "APPENDIX")
