Riello UPS CSS sentryum CBM User Manual

- 4 -
PREPARATIONS
READ THE "SAFETY MANUAL" BEFORE STARTING THE CSS INSTALLATION
INSTALLATION ENVIRONMENT
When choosing the site in which to install the CSS and the Battery Cabinet, the following points should be taken into consideration:
 Avoid dusty environments
 Check that the floor is level and capable of withstanding the weight of the CSS and the Battery Cabinet
 Avoid cramped environments that could impede the normal maintenance activities
 The relative humidity should not exceed 90%, non-condensing
 Avoid installing the equipment in places exposed to the direct sunlight or hot air
 This equipment is intended for use in a controlled environment; hence the temperature must be regulated within a range
between 0 and 40°C
The CSS may be operated within an ambient temperature of between 0 to 40°C. The recommended working
temperature for the CSS and batteries is between 20 to 25°C. Please note, the battery life is halved if the
working temperature is increased by 10°C.
To maintain the temperature of the installation room to within the range indicated above, there must be a system for eliminating the
dissipated heat (the CSS kW / kcal/h / B.T.U./h dissipation values are shown in the table below). The methods that may be used are:
 Natural ventilation
 Forced ventilation, recommended if the outside temperature is less (e.g. 20°C) than the temperature at which the CSS or
Battery Cabinet is to be operated (e.g. 25°C)
 Air-conditioning system, recommended if the outside temperature is higher (e.g. 30°C) than the temperature at which the
CSS or Battery Cabinet is to be operated (e.g. 25°C)
AMBIENT AND DIMENSION DETAIL
Table 1
Ambient temperature for the CSS 0 - 40°C
Recommended temperature for battery life 20 - 25°C
Range of relative Humidity 5 - 95% (without condensing)
Maximum Operating Altitude
(according with IEC/EN 62040-3)
Full power up to 1000 m a.s.l.
(power derating of 0.5% for each 100 m between 1000 and 4000 m)
Storage Temperature CSS: -25°C ÷ +60°C Batteries: -15°C ÷ +40°C
Isolation protection
IP20
(IP21, IP30, IP31 are available on request)
Colour RAL 7016
Ventilation
Forced, front to rear
(Air filter Door as option)
Cable input Bottom
Pollution degree PD2
Vibration resistance 1 m/s
2
Overvoltage category / Protective class OVC II / class I
CSS Dimension (WxDxH) [mm] 440 x 840 x 1320
CSS size [kVA] 6 8 10 15 20
Size according to EN 50171 [kW] 5 6 8 12 16
Shipping Weight without batteries [kg] 122 122 123 125 127
Shipping Weight with full battery configuration [kg] 431 431 432 434 436
Weight without batteries [kg] 102 102 103 105 107
Weight with full battery configuration [kg] 411 411 412 414 416
Battery
(maximum quantity that can be housed internally)
Space for: 3 x (20+20) 7/9 Ah blocks
(Output transformer alternative to internal batteries)
