Technical description of the burner
3.1 Burner designation
3.2 Models available
Tab. A
3.3 Burner categories - Countries of destination
Tab. B
3 Technical description of the burner
Designation Voltage Code
RIELLO 40 FS15 1/230/50 3756803
Range: RIELLO 40 F
Size
Fuel: Natural gas
Gas oil
LPG
Variations:
Electrical supply of the system: 1/230/50
1/230/60
F S 15 1/230/50
BASIC DESIGNATION
EXTENDED DESIGNATION
1/230V/50Hz
1/230V/60Hz
Light oil - Natural gas
K Conical head
S Reduced ignition output
D Two-stage
R Light oil with pre-heater
S
-
SP
D
Head:
TC Standard head
TL Long head
Country of destination Gas category
AT - BG - CH - CZ - DK - EE - FI - GR - HU - IS - IT - LT - NO -
RO - SE - SK - SI - TR
II2H3B/P
ES - GB - IE - PT II2H3P
LU - PL II2E3B/P
FR II2Er3P
BE I2E(R) I3P
LU - PL I2E
DE II2ELL3B/P
CY - MT I3B/P
NL II2EK3B/P
LV I2H
