SHUTDOWN
65
APPENDIX
APPENDIX
Menu item Sub item / Parameter Range Default Value Units User level
(125) Prog. Output 1.
0) Disabled
1) General Pump
2) CH Pump
3) DHW Pump
4) System Pump
5) Cascade Pump
6) Alarm Relay
7) Filling Valve
8) LPG Tank
9) External Igniter
10) Air Damper
14) Alarm Burner CC
15) Status Burner CC
16) Zone pump
17 )Mixing valve open
18 )Mixing valve closed
19) Anti-legionella pump
Managing: 2
Dependent: 2
2: Installer
(126) Prog. Output 2.
0) Disabled
1) General Pump
2) CH Pump
3) DHW Pump
4) System Pump
5) Cascade Pump
6) Alarm Relay
7) Filling Valve
8) LPG Tank
9) External Igniter
10) Air Damper
14) Alarm Burner CC
15) Status Burner CC
16) Zone pump
17) Mixing valve open
18) Mixing valve closed
19) Anti-legionella pump
Managing: 6
Dependent: 6
2: Installer
(127) Prog. Output 3.
0) Disabled
6) Alarm Relay
10) Air Damper
11) HSI / ext. igniter
Managing: 0
Dependent: 0
2: Installer
(128) Prog. Output 4.
0) Disabled
1) General Pump
2) CH Pump
3) DHW Pump
4) System Pump
5) Cascade Pump
6) Alarm Relay
7) Filling Valve
8) LPG Tank
9) External Igniter
10) Air Damper
14) Alarm Burner CC
15) Status Burner CC
16)Zone pump
17)Mixing valve open
18)Mixing valve closed
19)Anti-legionella pump
J3 1-7
Managing: 3 (3-
way valve CH)
Dependent: 3 (3-
way valve CH)
J3 2-7
Managing: 3 (3-
way valve DHW)
Dependent: 3 (3-
way valve DHW)
2: Installer
