10 WARRANTY
The Multi Switch is covered by a guarantee valid from the date it was bought. The guarantee does not include
equipment that is used incorrectly, or is modified due to circumstances external to the machine or to force major, is
repaired by third parties, or if the serial number has been removed or modified.
11 TECHNICAL DATA
Input voltage (V)
Min. 180Vac (RMS) single-phase with one line supplying, 50/60Hz
Max. 265Vac (RMS) single-phase with two lines supplying, 50/60Hz
Maximum load each output (A)
4
Maximum load each input (A)
16
Output voltage (V)
that of the line input voltage chosen
Mean relay intervention time (ms)
8
Operating conditions
Elevation max. 3,000 m (10,000ft) / <90% non-condensing humidity /
040°C
Storage conditions
Elevation max. 15,000m (50,000ft) / 045°C
Audible noise at 1m (3ft)
<25dBA
Communication ports
1 RJ-45 10BASE-T for SNMP network adapter version
1 DB9-F RS232 for serial port RS232 version
Casing index of protection
IP20
Safeguards
Overload
Input sockets
2 IEC (16A)
Circuit breaker
16A for each input socket
Output sockets
8 IEC 320 (10A)
Weight (Kg)
10
Rack measurements
2U–19’’
(1)
Depth
360mm
(1)
U=44.4mm
