Rietschle VCH 100 - English



VCH
VCH 100
VCH 140
VCH 180
VCH 250
VCH 100 / 140
VCH 180 / 250
VCH 180 250
a 826 mm 889 mm
a
1
506 mm 549 mm
a
2
511 mm 569 mm
a
3
71 mm 87 mm
b 647 mm 669 mm
e 375 mm 405 mm
l 231 mm 252 mm
r 221 mm 249 mm
[mm]
[mm]
Operating Instructions
Vacuum pumps
A Vacuum connection
B Exhaust air connection
E Cooling air entry
F Cooling air exit
H Oil filling point
I Oil check
K, K
1
Oil drain point
M Oil type plate
N Data plate
O Direction of rotation
U Gas ballast valve
