RigExpert TI-5000 - Annex 2: Adjusting Input and Output Audio Levels

User’s manual
16
Annex 2
Adjusting input and output
audio levels
You can adjust input and output audio levels by regulators on the front panel.
However, it is possible to increase range of input and output audio levels by using 6
switches which are located on bottom side of TI-5000.
ON
OFF
123456
ON
OFF
ON
OFF
ON
OFF
Main
ON
OFF
ON
OFF
ON
OFF
Sub
ON
OFF
ON
OFF
Mic
ON
OFF
ON
OFF
Out
1:1
1:10
1:100
1:1
1:10
1:100
1:1
1:2
1:1
1:10
