User’s manual
Thank you for purchasing a RigExpert
TI-5000 USB Transceiver Interface! We
did our best to make it powerful yet easy
to use.
RigExpert TI-5000 is a device for
operating phone, CW and digital modes
using personal computer with USB port.
It provides:
• Transceiver audio interface
Analog audio interface is a connection
to transceiver audio output (external
speaker connector or line output) and
transceiver audio input (microphone
connector or line input). Audio interface
enables operating digital modes,
recording and playing voice, as well
as other useful functions (such as
measuring levels of a signal from the air)
by using a computer.
Introduction
Input (main and sub channels) and
output volume levels are adjusted by
potentiometers on the front panel of the
device.
• CAT interface for various transceiver
models
CAT (Computer Aided Transceiver)
system provides control of transceiver
frequency, operating mode and other
functions by computer software. Nor-
mally, modern transceivers have serial
(with various signal levels) link providing
CAT interface.
A separate COM port is created for the
CAT system so the computer software can
communicate to the transceiver.
4
