Chapter 2 Front Panel Operations RIGOL
DG1000Z User’s Guide 2-21
StairUp Stair-up waveform
Trapezia Trapezia waveform
Engine
AmpALT
Gain oscillation curve
AttALT
Attenuation oscillation curve
RoundHalf
RoundHalf Wave
RounsPM RoundsPM Waveform
BlaseiWave Time-velocity curve of explosive vibration
DampedOsc Time-displacement curve of damped oscillation
SwingOsc
Kinetic energy- time curve of swing oscillation
Discharge
Discharge curve of Ni-MH battery
Pahcur Current waveform of DC brushless motor
Combin Combination function
SCR SCR firing profile
Filter
Butterworth
Butterworth filter
Chebyshev1
Chebyshev1 filter
Chebyshev2
Chebyshev2 filter
Signal
TV TV signal
Voice Voice signal
Surge Surge signal
Radar
Analog radar waveform
DualTone
Dual-tone signal
Ripple
Ripple wave of battery
Quake Analog quake waveform
Gamma Gamma signal
StepResp Step-response signal
BandLimited
Bandwidth-limited signal
CPulse
C-Pulse
CWPulse
CW pulse
GateVibr Gate self-oscillation signal
LFMPulse Linear FM pulse
MCNoise Mechanical construction noise
Mod
AM
Sectioned sine AM signal
FM
Sectioned sine FM signal
PFM Sectioned pulse FM signal
PM Sectioned sine PM signal
PWM Sectioned PWM signal
Medical
BIO
Cardiac
Cardiac signal
EOG Electro-Oculogram
EEG Electroencephalogram
EMG Electromyogram
Pulseilogram
Pulsilogram
ResSpeed
Speed curve of the respiration
