RIGOL Chapter 1 Test Overview
DL3000 Performance Verification Manual
1-2
Test Preparations
Before performing the performance verification test, make the following
preparations.
1. Perform the self-inspection to make sure that the instrument can work normally.
Plug the specified power cord available in the accessories into the AC power
supply connector of the instrument, and then connect the instrument to the
properly grounded AC power. Press the Power key , and then the
instrument is launched and begins to perform the self-inspection. If the
instrument passes the self-inspection, the instrument starts normally with a
splashing screen. If the self-inspection fails, please turn off the instrument and
then turn it on again to execute the self-inspection. If the problem still persists,
contact RIGOL. Ensure that you locate the problem for self-inspection failure
and resolve the problem properly. You are not allowed to perform the
performance verification test until the instrument passes the self-inspection test.
Note:
1) Before connecting to power, make sure that the setting of the voltage
selector on the rear panel of DL3000 series matches the AC power supply to
be connected. Ensure that the fuse currently installed matches the input
voltage. The specifications for AC input voltages and their matched fuses
supported by the DL3000 series are as shown in Table 1-1.
Table 1-1 AC Input Voltage and Fuse Rating
AC Selector
AC Input Voltage
Fuse Rating
115 Vac
± (10% of AC input + 115 Vac),
50 Hz to 60 Hz
T0.315 A/250 V
230 Vac
± (10% of AC input + 230 Vac)
(max: 250 Vac), 50 Hz to 60 Hz
T0.20 A/250 V
Note: The upper limit of the AC input voltage supported by the DL3000
series is 250 Vac.
2) Before performing the self-inspection, make sure that no load is connected
to the terminals on the front and rear panels of the instrument.
2. Make sure that the instrument is used within its calibration period (1 year). If
calibration is required, please contact RIGOL.
3. Warm up the instrument for at least 30 minutes.
4. Make sure that the ambient temperature is between 18℃ and 28℃, and the
relative humidity is less than 80%.
