Rigol DP811 - To Enable the Delayer

RIGOL Chapter 2 Front Panel Operations
2-30 DP800 User Guide
To Enable the Delayer
After setting the delay parameters, return to the timer and delayer interface (as
shown in Figure 2-1). Press Delayer to enable the delay output. The delay output
interface is as shown in the figure below.
Figure 2-5 Delay Output Interface
Tip
 Enabling the delayer will change the output state of the channel. Please
make sure that the change of the output state will not affect the devices
connected to the power supply before enabling the delayer.
 When the delayer is enabled, the delayer parameters cannot be modified
and Timer is grayed out and disabled.
