Chapter 2 Front Panel Operations RIGOL
DP800 User Guide 2-65
Maximum
0V
Minimum
0V
Mean Deviation
0V
Monitor
Channel
CH1
Monitor Switch
Off
Monitor Condition
>Volt
Voltage
Half of the rated value of CH1 (for DP813/DP811, it is half of the
rated value of Range1)
Current
Half of the rated value of CH1 (for DP813/DP811, it is half of the
rated value of Range1)
Power
The product of the two values above
Stop Mode
Output Off, Warning, Beeper
Trigger
Trig
In
Trigger Input
Data Line
D0
Source under Control
CH1
Trigger Type
Rise Edge
Output Response
Output Off
Sensitivity
Low
Enable
No
Trigger Output
Data Line
D0
Control Source
CH1
Trigger Condition
Output Off
Output Signal
Level
Square
Period: 1s; Duty Cycle: 50%
Polarity
Positive
Enable
No
Store
Browser
Directory
Directory
C:\
File
The first file
File Type
*.rsf
Note*: These parameters are not affected by factory reset (when "Default" is selected in Utility
 System  Power On, restarting the power supply will restore it to the factory setting).
