Chapter 5 Specifications RIGOL
DP800 User Guide 5-3
1mV
1mV
0.1mA
1mA
1mV
1mV
0.1mA
1mA
1mV
1mV
0.1mA
1mA
DP813 CH1
Standard
10mV
10mA
10mV
10mA
10mV
10mA
With the high-resolution option
1mV
1mA
1mV
1mA
1mV
1mA
DP811 CH1
Standard
10mV
10mA
1mV
1mA
10mV
10mA
With the high-resolution option
1mV
0.5mA
0.1mV
0.1mA
1mV
1mA
Transient Response Time
Less than 50μs for output voltage to recover to within 15mV following a change in output current
from full load to half load or vice versa.
Command Processing Time
[2]
<118ms
OVP/OCP
Accuracy ±(Output Percentage+Offset)
0.5%+0.5V/0.5%+0.5A
Voltage Programming Control Speed (1% within the total variation range)
Channel
Rise
Fall
Full Load
No Load
Full Load
No Load
DP832
CH1
CH2
CH3
<50ms
<50ms
<15ms
<33ms
<38ms
<14ms
<46ms
<46ms
<24ms
<400ms
<400ms
<100ms
DP831
CH1
CH2
CH3
<18ms
<33ms
<35ms
<17ms
<36ms
<42ms
<20ms
<44ms
<45ms
<200ms
<400ms
<400ms
DP822
CH1
CH2
<30ms
<15ms
<30ms
<15ms
<30ms
<15ms
<1000ms
<250ms
DP821
CH1
CH2
<110ms
<15ms
<30ms
<15ms
<110ms
<20ms
<800ms
<400ms
DP813
CH1
<30ms
<30ms
<20ms
<1500ms
DP811
CH1
<45ms
<42ms
<51ms
<1089ms
Temperature Coefficient per ℃ (Output Percentage+Offset)
Channel
Voltage
Current
DP832
CH1
CH2
CH3
0.01%+5mV
0.01%+5mV
0.01%+2mV
0.01%+2mA
0.01%+2mA
0.01%+2mA
