Chapter 2 Front Panel Operations RIGOL
DP800 User Guide 2-63
DP813
Voltage/Current Setting
Values
00.00V/20.00A
Voltage/Current Limits
8.80V/22.00A
OVP/OCP On/Off
Off/Off
Output On/Off
Off
Sense Function On/Off
Off
Current Range
Range1
DP811
Voltage/Current Setting
Values
00.00V/05.00A
Voltage/Current Limits
22.00V/11.00A
OVP/OCP On/Off
Off/Off
Output On/Off
Off
Sense Function On/Off
Off
Current Range
Range1
Display
Brightness*
50%
Contrast*
25%
RGB Luminance*
50%
Display Mode*
Normal
Theme*
Green
System Setting
Language*
Chinese(s)
Power-on Setting*
Default
OTP
On
Beeper
On
Screen Saver
Off
Keyboard Lock*
Off
Track M ode
Synchronous
On/Off Sync
Disable
Preset
Default
Print Destination
USB Disk
Print Copies
1
Print Format
BMP
Print Invert
Yes
Print Color
GrayScale
I/O Configuration*
GPIB Address
2
RS232
Baud Rate
9600
Data Bit
8
Stop Bit
1
Parity Bit
None
Hardware Flow Control
Off
