Rigol DP831A Performance Verification Manual

Chapter 2 Constant Voltage Tests RIGOL
DP800 Performance Verification Manual
2-9
Test Record Forms:
Table 2-7 DP831A CV Linear Regulation Rate Test Record Form
Channel CH1 (8V/5A) CH2 (30V/2A) CH3 (-30V/2A)
Specification <2.8mV <5mV <5mV
DP831A
Setting
Voltage 8V 30V -30V
Current 5.3A 2.1A 2.1A
Measurement
Result
U
0
U
1
U
2
|U
1
-U
0
|
|U
2
-U
0
|
Table 2-8 DP832A CV Linear Regulation Rate Test Record Form
Channel CH1 (30V/3A) CH2 (30V/3A) CH3 (5V/3A)
Specification <5mV <5mV <2.5mV
DP832A
Setting
Voltage 30V 30V 5V
Current 3.2A 3.2A 3.2A
Measurement
Result
U
0
U
1
U
2
|U
1
-U
0
|
|U
2
-U
0
|
Table 2-9 DP832 CV Linear Regulation Rate Test Record Form
Channel CH1 (30V/3A) CH2 (30V/3A) CH3 (5V/3A)
Specification <5mV <5mV <2.5mV
DP832
Setting
Voltage 30V 30V 5V
Current 3.2A 3.2A 3.2A
Measurement
Result
U
0
U
1
U
2
|U
1
-U
0
|
|U
2
-U
0
|
