Rigol DP831A Performance Verification Manual

Appendix RIGOL
DP800 Performance Verification Manual
21
Appendix B: Specifications
The following parameters can only be guaranteed when the instrument has been
operated continuously for more than 30 minutes under the specified operating
temperature.
Note: Unless otherwise noted, the specifications below apply to all channels (ranges)
of the specified model.
DC Output (0℃-40℃)
Channel
Rated Value Maximum Settable Range
Voltage Current
Overvoltage
Protection
Overcurrent
Protection
DP831A
CH1
CH2
CH3
0V~8V
0V~30V
-30V~0V
0A~5A
0A~2A
0A~2A
1mV~8.8V
1mV~33V
-1mV~-33V
0.1mA~5.5A
0.1mA~2.2A
0.1mA~2.2A
DP832A
CH1
CH2
CH3
0V~30V
0V~30V
0V~5V
0A~3A
0A~3A
0A~3A
1mV~33V
1mV~33V
1mV~5.5V
1mA~3.3A
1mA~3.3A
1mA~3.3A
DP832
CH1
CH2
CH3
0V~30V
0V~30V
0V~5V
0A~3A
0A~3A
0A~3A
10mV~33V
10mV~33V
10mV~5.5V
1mA~3.3A
1mA~3.3A
1mA~3.3A
DP821A
CH1
CH2
0V~60V
0V~8V
0A~1A
0A~10A
1mV~66V
1mV~8.8V
0.1mA~1.1A
1mA~11A
DP811A
Range1
Range2
0V~20V
0V~40V
0A~10A
0A~5A
1mV~22V
1mV~44V
0.1mA~11A
0.1mA~5.5A
Load Regulation rate, ±(Output Percentage+Offset)
Voltage <0.01%+2mV
Current <0.01%+250μA
Linear Regulation Rate, ±(Output Percentage+Offset)
Voltage <0.01%+2mV
Current <0.01%+250μA
Ripple and Noise (20 Hz to 20 MHz)
Normal Mode Voltage <350μVrms/2mVpp
Normal Mode Current <2mArms

Rigol DP831A Specifications

General

Brand	Rigol
Model	DP831A
Category	Power Supply
Language	English
