Rigol DP831A Performance Verification Manual

RIGOL Chapter 2 Constant Voltage Tests
DP800 Performance Verification Manual
2-14
Test Record Forms:
Table 2-12 DP831A CV Ripple and Noise Test Record Form
Channel CH1 (8V/5A) CH2 (30V/2A) CH3 (-30V/2A)
Specification <350μVrms/3mVpp
Resistive Load R
L
1.6Ω 15Ω 15Ω
DP831A
Setting
Voltage 8V 30V -30V
Current 5.3A 2.1A 2.1A
Measurement
Result
Peak-peak value
(Vpp)
RMS value
(Vrms)
Table 2-13 DP832A CV Ripple and Noise Test Record Form
Channel CH1 (30V/3A) CH2 (30V/3A) CH3 (5V/3A)
Specification <350μVrms/3mVpp
Resistive Load R
L
10Ω 10Ω 1.6Ω
DP832A
Setting
Voltage 30V 30V 5V
Current 3.2A 3.2A 3.2A
Measurement
Result
Peak-peak value
(Vpp)
RMS value
(Vrms)
Table 2-14 DP832 CV Ripple and Noise Test Record Form
Channel CH1 (30V/3A) CH2 (30V/3A) CH3 (5V/3A)
Specification <350μVrms/3mVpp
Resistive Load R
L
10Ω 10Ω 1.6Ω
DP832 Setting
Voltage 30V 30V 5V
Current 3.2A 3.2A 3.2A
Measurement
Result
Peak-peak value
(Vpp)
RMS value
(Vrms)
