Chapter 2 Constant Voltage Tests RIGOL
DP800 Performance Verification Manual
2-19
Table 2-19 DP832 Transient Response Time Test Record Form
Channel CH1 (30V/3A) CH2 (30V/3A) CH3 (5V/3A)
Specification <50μs
DP832 Setting
Voltage 30V 30V 5V
Current 3.2A 3.2A 3.2A
Electronic
Load Current
Setting
CCDH1 3A 3A 3A
CCDH2 1.5A 1.5A 1.5A
Measurement
Result
t
Table 2-20 DP821A Transient Response Time Test Record Form
Channel CH1 (60V/1A) CH2 (8V/10A)
Specification <50μs
DP821A
Setting
Voltage 60V 8V
Current 1.05A 10.5A
Electronic
Load Current
Setting
CCDH1 1A 10A
CCDH2 0.5A 5A
Measurement
Result
t
Table 2-21 DP811A Transient Response Time Test Record Form
Range Range1 (20V/10A) Range2 (40V/5A)
Specification <50μs
DP811A
Setting
Voltage 20V 40V
Current 10.5A 5.3A
Electronic
Load Current
Setting
CCDH1 10A 5A
CCDH2 5A 2.5A
Measurement
Result
t
