Appendix RIGOL
DP800 Performance Verification Manual
11
CC Load Regulation Rate
Channel CH1 (30V/3A) CH2 (30V/3A) CH3 (5V/3A)
Specification <550μA
DP832
Setting
Voltage 32V 32V 5.3V
Current 3A 3A 3A
Measurement
Result
U
0
U
1
|U
1
/R
M
[2]
-U
0
/R
M
[2]
|
CC Linear Regulation Rate
Channel CH1 (30V/3A) CH2 (30V/3A) CH3 (5V/3A)
Specification <550μA
DP832
Setting
Voltage 32V 32V 5.3V
Current 3A 3A 3A
Measurement
Result
U
0
U
1
U
2
|U
1
-U
0
|/R
M
[2]
|U
2
-U
0
|/R
M
[2]
CC Ripple and Noise
Channel CH1 (30V/3A) CH2 (30V/3A) CH3 (5V/3A)
Specification <2mArms
Resistive Load R
L
10Ω 10Ω 1.6Ω
DP832 Setting
Voltage 32V 32V 5.3V
Current 3A 3A 3A
Measurement
Result
RMS value (Vrms)
Vrms/R
L
