Rigol DP831A

Appendix RIGOL
DP800 Performance Verification Manual
15
CC Load Regulation Rate
Channel CH1 (60V/1A) CH2 (8V/10A)
Specification <350μA <1.25mA
DP821A
Setting
Voltage 63V 8.4V
Current 1A 10A
Measurement
Result
U
0
U
1
|U
1
/R
M
[2]
-U
0
/R
M
[2]
|
CC Linear Regulation Rate
Channel CH1 (60V/1A) CH2 (8V/10A)
Specification <350μA <1.25mA
DP821A
Setting
Voltage 63V 8.4V
Current 1A 10A
Measurement
Result
U
0
U
1
U
2
|U
1
-U
0
|/R
M
[2]
|U
2
-U
0
|/R
M
[2]
CC Ripple and Noise
Channel CH1 (60V/1A) CH2 (8V/10A)
Specification <2mArms
Resistive Load R
L
60Ω 0.8Ω
DP821A
Setting
Voltage 63V 8.4V
Current 1A 10A
Measurement
Result
RMS value (Vrms)
Vrms/R
L
