Rigol DS1052E Datasheet

5
General Specifications
Display
Display Type
145mm (5.6 inch) diagonal TFT Liquid Crystal Display
Display Resolution
320 horizontal ×RGB×234 vertical pixels
Display Color
64k color
Display Contrast (typical)
150:1
Backlight Brightness (typical)
300 nit
Probe Compensator Output
Output Voltage (typical)
Approximately 3Vpp (peak to peak value)
Frequency (typical)
1kHz
Power Supply
Supply Voltage
100 ~ 240VAC
RMS
, 45~440Hz, CAT II
Power Consumption
Less than 50W
Fuse
2A, T level, 250 V
Environmental
Ambient Temperature
Operating 10
℃
~ 40
℃
Non-operating -20
℃
~ +60
℃
Cooling Method
fan cooling
Humidity
below +35
℃
: ≤90% relative humidity
+35
℃
~ +40
℃
: ≤60% relative humidity
Altitude
Operating at 3,000 m or below
Non-operating at 15,000 m or below
Mechanical
Dimensions
Width
303mm
Height
154mm
Depth
133mm
Weight
Without package
2.3kg
Packaged
3.5kg
IP Protection
IP2X
Calibration Interval
The recommended calibration interval is one year

Rigol DS1052E Specifications

General

Bandwidth	50 MHz
Sample Rate	1 GSa/s
Channels	2
Memory Depth	1 Mpts
Vertical Sensitivity	2 mV/div to 10 V/div
Input Impedance	1 MΩ ± 2% || 15 pF ± 3 pF
Vertical Resolution	8 bits
Trigger Modes	Edge, Pulse, Video, Slope, Alternate
Power Supply	100-240 V AC, 45-440 Hz
Display	5.7 inch TFT LCD
Interfaces	USB Host, USB Device, RS-232
Dimensions	303 mm x 154 mm x 133 mm
