User’s Guide for DS1000E, DS1000D Series
2-49
Figure 2- 65 Table 2- 41 The Trigger Set Up Menu (Settings only for holdoff)
Menu Settings Comments
Holdoff
<Holdoff Setting>
Set time slot before another
trigger event
Holdoff Reset Reset Holdoff time to 500ns
