Rigol DS6000 Series Performance Verification Guide

Chapter 2 Performance Verification Test RIGOL
DS6000 Performance Verification Guide
2-11
4. Output a sine signal with 1 MHz frequency and 1.2 Vpp amplitude via Fluke 9500B.
5. Press MENU  Vrms at the left side of the screen of the oscilloscope to enable the effective
value measurement function. Read and record Vrms1.
6. Output a sine signal with 1 GHz frequency (the setting value is different for different model of
oscilloscope under test; please refer to Table 2-2) and 1.2 Vpp amplitude via Fluke 9500B.
Table 2-2 Setting Value of the Oscilloscope under Test
Model Full Bandwidth Horizontal Time Base
DS606X 600 MHz 1 ns
DS610X 1 GHz 500 ps
7. Rotate HORIZONTAL
SCALE of the oscilloscope to set the horizontal time base to 500 ps
(the setting value is different for different model of oscilloscope under test; please refer to
Table
2-2).
8. Press MENU  Vrms at the left side of the screen of the oscilloscope to enable the effective
value measurement function. Read and record Vrms2.
9. Calculate the amplitude loss: Amplitude Loss (dB) = 20 × lg (Vrms2/Vrms1).
10. Keep the other settings of the oscilloscope in step 3 unchanged and set the vertical scale to 500
mV/div.
11. Output a sine signal with 1 MHz frequency and 3 Vpp amplitude via Fluke 9500B.
12. Repeat step 5.
13. Output a sine signal with 1 GHz frequency (the setting value is different for different model of
oscilloscope under test; please refer to Table 2-2) and 3 Vpp amplitude via Fluke 9500B.
14. Repeat steps 7 to 9.
15. Turn off CH1. Test CH2, CH3 and CH4 respectively using the above test steps and record the test
results.
