RIGOL Chapter 1 Overview
DSA1000A/DSA1000 Performance Verification Guide
The test devices required (continue)
Device Specification Qty. Recommended
Step Attenuator
Step: 1 dB
Attenuation range: 0 dB to 11 dB
Frequency range: 50 MHz ± 1 MHz
Connector: N-type (female)
Attenuation Repeatability: ±0.03 dB
1 Agilent 8494H
Step Attenuator
Step: 10 dB
Attenuation range: 0 dB to 110 dB
Frequency range: 50 MHz ± 1 MHz
Connector: N-type (female)
Attenuation Repeatability: ±0.03 dB
1 Agilent 8496H
Attenuator
Interconnect Kit
Connect Agilent 8494H and Agilent 8496H 1 Agilent 11716A
50 Ω Load
Impedance: 50 Ω, rated
Connector: N-type (male)
1
--
Power Meter
Connecting Cable
Compatible with Agilent N1913A power meter and Agilent
E9304A power sensor
1
--
Dual-N Cables N-type (male) to N-type (male) cable 3
--
Dual-BNC Cable BNC (male)-BNC (male) cable 1
--
N-SMA Cables N-type (male) to SMA (male) cable 2
--
Note: [1] The connecting terminals of the low-pass filter used in this manual are two SMA female terminals. In the
actual test, the type of the connecting terminals of the low-pass filter may differ; please select proper connecting
cable and adaptor according to the actual type of the connecting terminals.
To Next Page
