Appendix RIGOL
DSA1000A/DSA1000 Performance Verification Guide
3
Second Harmonic Distortion Test:
Output Frequency of
Signal Generator
Delta Calculation Result
[1]
Limit
Pass/
Fail
1 GHz > 35 dBm
Note: [1] Calculation Result = -20 dBm - Delta (-20 dBm is the level input into the mixer).
TOI Distortion Test:
Center Frequency Delta Calculation Result
[1]
Limit
Pass/
Fail
999.8 MHz
> 7 dBm
1.0004 GHz
Note: [1] Calculation Result = -20 dBm - Delta/2 (-20 dBm is the level input into the mixer).
1 dB Gain Compression Test:
Output Amplitude of
Signal Generator B
Measurement
Result A1
Measurement Result
A2
Calculation
Result
[1]
Limit
Pass/
Fail
0 dBm < 1 dBm
Note: [1] Calculation Result = A1 - A2.
Input Attenuation Error Test:
System Error Reference Value
Global Error Reference Value
Reference
Level
Internal
Attenuator
Program-
controlled
Attenuator
System
Error
[1]
Global
Error
[2]
Uncertainty
[3]
Limit
Pass
/Fail
-50 dBm 0 dB 50 dB
DSA1030A:
< (0.3 +
0.01 ×
internal
attenuator
setting) dB
DSA1030:
< 0.8 dB
-49 dBm 1 dB 49 dB
-48 dBm 2 dB 48 dB
-47 dBm 3 dB 47 dB
-46 dBm 4 dB 46 dB
-45 dBm 5 dB 45 dB
-44 dBm 6 dB 44 dB
-43 dBm 7 dB 43 dB
-42 dBm 8 dB 42 dB
-41 dBm 9 dB 41 dB
-40 dBm 10 dB 40 dB
-39 dBm 11 dB 39 dB
-38 dBm 12 dB 38 dB
-37 dBm 13 dB 37 dB
-36 dBm 14 dB 36 dB
-35 dBm 15 dB 35 dB
-34 dBm 16 dB 34 dB
-33 dBm 17 dB 33 dB
