:BUS<n>:RS232:BAUD
Syntax
:BUS<n>:RS232:BAUD <baud>
:BUS<n>:RS232:BAUD?
Description
Sets or queries the baud rate of data transmission in RS232 decoding.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2|3|4}
——
<baud>
Integer
1 bps to 20 Mbps
9600 bps
Remarks
If the baud rate is set to a value with "M", then "A" should be added at the end of the
value. For example, if you send 5 M, you need to send 5 MA.
Return
Format
The query returns an integer ranging from 1 bps to 20 Mbps.
Example
:BUS1:RS232:BAUD 4800 /*Sets the baud rate of data transmission in RS232
decoding to 4800 bps.*/
:BUS1:RS232:BAUD? /*The query returns 4800.*/
:BUS<n>:RS232:DBITs
Syntax
:BUS<n>:RS232:DBITs <bits>
:BUS<n>:RS232:DBITs?
Description
Sets or queries the data width of RS232 decoding.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2|3|4}
——
<bits>
Discrete
{5|6|7|8|9}
8
Return
Format
The query returns 5, 6, 7, 8, or 9.
Example
:BUS1:RS232:DBITs 7 /*Sets the data width of RS232 decoding to 7.*/
:BUS1:RS232:DBITs? /*The query returns 7.*/
:BUS<n>:RS232:SBITs
Syntax
:BUS<n>:RS232:SBITs <stop bits>
:BUS<n>:RS232:SBITs?
Description
Sets or queries the stop bits of each frame of data in RS232 decoding.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2|3|4}
——
<stop bits>
Discrete
{1|1.5|2}
1
Return
Format
The query returns 1, 1.5, or 2.
Example
:BUS1:RS232:SBITs 2 /*Sets the stop bits of RS232 decoding to 2.*/
:BUS1:RS232:SBITs? /*The query returns 2.*/
