⚫ Set start frequency and end frequency
Start frequency and end frequency indicate the upper and lower limits of
the sweep frequency. The Function/Arbitrary Waveform Generator always
sweeps from the start frequency to the end frequency, and then returns
back to the start frequency.
➢ When start frequency is smaller than the end frequency, the
Function/Arbitrary Waveform Generator sweeps from low frequency to
high frequency.
➢ When start frequency is greater than the end frequency, the
Function/Arbitrary Waveform Generator sweeps from high frequency
to low frequency.
➢ When start frequency is equal to the end frequency, the
Function/Arbitrary Waveform Generator outputs at a fixed frequency.
Press Start Freq, then rotate the multifunction knob or use the
pop-up numeric keypad to set the start frequency. Press End Freq, then
rotate the multifunction knob or use the pop-up numeric keypad to set
the end frequency. By default, the start frequency is 100 Hz, and the end
frequency is 1 kHz. The ranges of start frequency and end frequency for
different sweep waveforms are different. After modifying the "Start Freq"
and "End Freq", the Function/Arbitrary Waveform Generator will restart to
output from the specified "Start Freq".
⚫ Start Keep
Start keep indicates the time that the output signal keeps outputting at the
"Start Freq" after the sweep starts. After the start keep time expires, the
Function/Arbitrary Waveform Generator will continue outputting at a
different frequency based on the current sweep type.
Press Start Keep, then rotate the multifunction knob or use the
pop-up numeric keypad to set the start keep time. The default is 0 s, and
the range is from 0 s to 500 s.
⚫ End Keep
End keep indicates the time that the output signal continues outputting at
the "End Freq" after the Function/Arbitrary Waveform Generator sweeps
from "Start Freq" to "End Freq".
Press End Keep, then rotate the multifunction knob or use the pop-up
numeric keypad to set the end keep time. The default is 0 s, and the range
is from 0 s to 500 s.
⚫ Set the step
When the sweep type is set to "Step", this menu is enabled and can be
settable. Press Step number, then rotate the multifunction knob or
