RIGOL Chapter 18 Store and Load
18-22 MSO7000/DS7000 User Guide
Thre.CH1
0 V
Thre.CH2
0 V
Thre.CH3
0 V
Thre.CH4
0 V
Sensitivity
0.3 Div
A^B
Operation
OFF
Source A
CH1
Source B
CH1
Wave Size
Medium
Thre.CH1
0 V
Thre.CH2
0 V
Thre.CH3
0 V
Thre.CH4
0 V
Sensitivity
0.3 Div
!A
Operation
OFF
Source A
CH1
Wave Size
Medium
Thre.CH1
0 V
Thre.CH2
0 V
Thre.CH3
0 V
Thre.CH4
0 V
Sensitivity
0.3 Div
Intg
Operation
OFF
Source
CH1
Offset
0 v*s
Scale
500 mv*s
Bias
0
Invert
OFF
Diff
Operation
OFF
Source
CH1
Offset
0 v/s
Scale
500 mv/s
Smooth
5
Invert
OFF
Sqrt
Operation
OFF
Source
CH1
Offset
0 U
Scale
500 mU
Invert
OFF
