Rigol MSO8000 Series Service Guide

Chapter 1 Disassembly and Assembly RIGOL
MSO8000 Service Guide 1-3
Table1-1 Replacement Parts List
No.
Part No.
Qty.
Name/Description
1
1020004447 (MSO8064)
1020004448 (MSO8104)
1
Front Label
2
1010005810
1
LCD (Touch Screen Included)
3
1020003979
1
LCD Shield
4
1020000573
30
M3x8 Torx Pan Head Combination Screw
5
1020000571
13
M3x6 Torx Pan Head Combination Screw
6
1010005842
8
BeCu Fingerstock
7
2010004397
1
Main Board (MB_BOARD)
8
1020003981
1
Power Supply Shield
9
1020003988
1
Metal Rear Panel
10
1010005841
3
BeCu Fingerstock (Slot Mount)
11
2010003934
1
Power Supply Board
12
2010003933
1
Rubber Fan Sleeve
13
1020004108
1
Dustproof Mesh
14
2010003941
1
Rear Panel
15
2010003929
1
Handle
16
1020004004
1
BNC Back Label
17
1020004003
1
LAN Interface Back Label
18
1020004002
1
HDMI Rear Label
19
1020004001
1
Authentication Back Label
20
2010000322
2
Rear Bracket
21
2010003927
2
Main Rear Support Leg
22
2010003928
2
Auxiliary Rear Bracket
23
2010000183
4
Bracket Shaft
24
2010000324
2
Bracing Shaft Restrain Block
25
1010003552
1
Fuse
26
1010002562
1
Power Socket
27
1020000563
1
M4x8 Torx Pan Head Combination Screw
28
1020003467
1
Fan
29
1020003987
1
Metal Front Panel
30
1020000648
9
Lock Washer
31
1020000619
9
BNC Nut
32
2010004101
1
Keypad Board
33
1020003991
1
Main Key
34
2010003942
1
Panel
35
2010001009
2
Front Bracket
36
1020004032
1
BNC Label
37
1020004000
1
Controls Film
38
2010003945
6
Large Knob
39
2010003947
8
Small Knob
40
1020003999
1
Front Panel Interface/Connector Label
41
1020003967
1
Power Key
The recommended disassembly procedures are as follows:
Disassemble the Rear Panel Components  Disassemble the Front Bracket  Disassemble the Metal
Rear Panel Components  Disassemble the Fan Components  Disassemble the Power Supply Shield
 Disassemble the Power Supply Board  Disassemble the Metal Front Panel  Disassemble the
Main Board  Disassemble the Knob  Disassemble the Keypad Board  Disassemble the LCD
 Disassemble the Power Key
