Rigol MSO8000 Series Service Guide

Chapter 1 Disassembly and Assembly RIGOL
MSO8000 Service Guide 1-7
Disassembly Steps:
1. Use the BNC socket wrench to remove the 3 BNC nuts and 3 lock washers at the BNC connectors
of the metal rear panel components.
2. Use the T10 screwdriver to remove 8 screws (①) that fasten the front metal panel and the metal
rear panel components.
3. Disconnect the power cable and the fan cable from the main board.
4. Remove the metal rear panel components gently.
Tip
Before disconnecting the power cable and the fan cable from the main board, pay attention to the
connecting positions of the cables to avoid incorrect connection or incomplete connection when
assembling the cables.
