RIGOL
MSO8000 快速指南 7
中文
图 2 后面板
表 2 后面板说明
编号
说明
1
手柄
2
LAN 接口
3
USB DEVICE 接口
4
USB HOST 接口
5
HDMI 高清视频输出
6
参考时钟输入/输出端
7
EXT 触发输入端
8
触发输出接口
9
Kensington 安全锁孔
10
保险丝
11
AC 电源插孔
1 2 3 4 5
11 10 9 8 7 6
