Chapter 1 Quick Start RIGOL

MSO7000/DS7000 User Guide 1-21

Quick Key (Shortcut Key)

Press this key to perform the quick operation, including screenshot,

waveform saving, setup saving, all measurement, and statistics reset.

Press Utility  More  Quick settings to set the quick shortcut

keys.
