Chapter 2 Functions of the Front Panel RIGOL
VNA User Guide 2-9
Auto Scale
Auto adjusts the graticule scale of the currently selected trace and the reference
value to make it optimal for display and observation.
All Auto Scale
Auto adjusts the graticule scale of all displayed traces and the reference value to
make them optimal for display and observation.
Remarks:
⚫ Once you enable this function, the graticule scale and reference position of the
corresponding traces will be updated automatically.
⚫ The All Auto Scale function only affects the display effects, but unable to affect
the measurement results.
