RIGOL Chapter 2 Functions of the Front Panel
2-32 VNA User Guide
Table 2-31 Velocity Factor
Parameter
Remarks
Default
0.66
Range
0.1 to 1
Unit
N/A
Knob Step
0.1
Left/Right Arrow Key Step
Up/Down Arrow Key Step
at 1-2-5 step
Port 1 Specific Loss
Sets the cable loss for Port 1.
Table 2-32 Cable Loss
Parameter
Remarks
Default
0.00 dB/m
Range
0.00 dB/m to 5.00 dB/m
Unit
dB/m
Knob Step
0.1 dB/m
Left/Right Arrow Key Step
Up/Down Arrow Key Step
at 1-2-5 step
Port 2 Delay
Sets the delay time for Port 2 extension.
The relationship between port delay and port length is correlative, as shown in the
following formula. Once one of the parameters is modified, other parameters will also
be modified.
  =
 
     
Table 2-33 Port 2 Delay
Parameter
Remarks
Default
0.00 ns
Range
-10.00 s to 10.00 s
Unit
us, ns, ps, fs, as
Knob Step
Port 2 delay/100
Left/Right Arrow Key Step
Up/Down Arrow Key Step
Port 2 delay/10
Port 2 Length
Sets the extension length for Port 2.
