Chapter 2 Functions of the Front Panel RIGOL
VNA User Guide 2-61
The default state filename is determined by the following methods:
⚫ If you haven't input a filename by pressing the Save As key, its default
filename is state<n>.sta. Wherein, n refers to the file number of the
filenames that are named based on the naming mode in the current file
directory. The value of <n> is the existing maximum file number plus 1. For
example, if 3 files (state1.sta、state2.sta、state5.sta) exist in the current
directory, then the new filename for the file that you want to save should be
state6.sta by default.
⚫ If you have pressed the Save As key to input the filename abc, then the file
is saved to be "abc.sta". After that, press the Save key again, another file is
saved automatically with the filename "abc1.sta".
2. Save As
Press this key and then use the numeric keypad on the front panel to input the
filename. Then, press Save to save the corresponding state file.
You can also touch the screen or use the mouse to touch or click the Save As
menu, and then input the filename with the keypad.
Trace&State
Press Trace&State to enter the trace&state saving menu. The state of the
instrument and the selected trace can be saved to the file.
1. Save
Press this key to save the current trace&state file in the default filename or
user-defined filename.
The default filename is determined by the following methods:
⚫ If you haven't input a filename by pressing the Save As key, its default
filename is tracestate<n>.trs. Wherein, n refers to the file number of the
filenames that are named based on the naming mode in the current file
directory. The value of <n> is the existing maximum file number plus 1.
⚫ If you have pressed the Save As key to input the filename abc, then the file
is saved to be "abc.trs". After that, press the Save key again, another file is
saved automatically with the filename "abc1.trs".
2. Save As
Press this key and then use the numeric keypad on the front panel to input the
filename. Then, press Save to save the corresponding trace+state file.
You can also touch the screen or use the mouse to touch or click the Save As
menu, and then input the filename with the keypad.
