Chapter 6 System Function RIGOL
RSA5000 User Guide 6-7
Security Clear
Press this key to perform the security clear function. This function includes the
following operations:
⚫ Deletes all the files that users have saved, including the state files, trace state
files, screen files, measdata files, and limit files saved by users in all modes.
⚫ Executes the factory resetting operation.
Language
RSA5000 supports multi-language menu, Chinese and English built-in help and
pop-up messages.
Press this key to select the desired display language.
Settings
1. Power Switch
Sets whether the power switch on the front panel is effective or not.
⚫ Default: When the analyzer is powered on, press the power switch on the
front panel to start up the analyzer.
⚫ Always: When the analyzer is powered on, it starts automatically.
2. Beep Switch
Turns on or off the beeper.
3. Volume
After you turn on the beeper, you can press this key to adjust the volume of the
beeper.
4. User Key
Defines an associated function for the User key on the front panel. The
definition method is as described below. After that, pressing User in any
operation interface can quickly enable the defined function.
⚫ Press User Key to select "On";
⚫ Open the function menu that needs to be defined. For example, press
System → Display → Display Line;
Press User and the definition is finished. At this time, User Key turns off
automatically.
5. SCPI Display
When you use the SCPI commands to control the instrument remotely, turning
on the SCPI Display will go to the specified menu of the corresponding
command; turning off the SCPI Display will not go to the specified menu.
