Dimensions
540
1092
420
673
1554
130
253
270
193
880
270
270
125
130
Dimensions
Height [mm]
Width [mm]
Corpus depth [mm]
Weight
Weight without shell [kg] ~
Weight with shell stone [kg] ~
Heat storage mass [kg] ~
Flue pipe connection
Flue pipe outlet [mm]
Original angle pipe connection height [mm]
Original angle pipe total depth [mm]
Original angle pipe distance to rear wall [mm]
Deapth from rear wall to middle of flue
pipe
[mm]
Original angle pipe side distance [mm]
Rear Connection Height [mm]
Rear Connection Side Distance [mm]
Fresh air connection
Diameter [mm]
Connection Height [mm]
Side Distance [mm]
Amount of fuel
Nominal load Part load
Amount of fuel 8 kW ~, kg* ~, kg*
Amount of fuel 6 kW ~, kg* -
*Practical values may vary depending on fuel quality.
Technical data
Technical data 8 kW 6 kW
Heating power range [kW]
Partial heat output [kW] -
Room heating capacity
(depending on house insulation)
[m
] - -
Fuel consumption [kg/h] up to , up to ,
Electric supply [V]/[Hz] / /
Average electrical input [W] ~ ~
Fuse [A] , AT , AT
Efficiency [%] , ,
CO
2
[%] , ,
CO-emission on 13% O
2
[mg/
m
N
]
,
Dust emission
[mg/
m
N
]
, ,
Exhaust [g/s] , ,
Exhaust temperature [°C] , ,
Chimney draft requirement [Pa]
The owner of small firing systems or the person authorised for the
small firing system is to keep the technical documentation and is to
submit it to the authorities or the chimney sweep on request.
Note
Please observe the national and European standards as well as
local regulations concerning the installation and operation of
firing installations!
Packaging
Your first impression is important to us!
The packaging of your new stove provides excellent protection
against damage. However damage to the stove and accessories
may still occur during transport.
Note
Therefore please check your stove on receipt for damage and
completeness! Report any deficiencies to your dealer immediately!
Pay particular attention during unpacking that the stone panels
remain intact. Scratches to the material can easily occur. Stone
panels are excluded from the warrant.
The packaging of your new stove is environmentally neutral to a
great extent.
Tip
The wood used in the packaging has not been surface treated
and may therefore be burnt in your woodburning stove (not in a
pelletstove!). The cardboard and film (PE) can be depolluted via
the municipal waste collection for recycling.
Electrical connection (Rikatronic4)
The stove is supplied with an approx. 2m long connecting cable
with a Euro-plug. This cable is to be connected to a 230Volt/50Hz
socket. The average electrical power consumption is about 4 Watt in
heating operation, and approx. 150 Watt during automatic ignition.
The connection cable must be laid in a way that there is no contact
to any sharp edges or hot surfaces of the stove.
