RIKA PREMIO - Page 7

7
Fig. 7
A Bus 1
B Bus 2
C Bus 3
a. Miniature fuse
b. Condenser
Fig. 8
1. HAL-RG fan
2. Operating panel
3. Tele pellet control
4. Air sensor
5. UTB
6. OTB
7. FKY 1
8. FKY 2
9. Alarm
I Network 230V a.c.
II RG fan
III Cross stream fan
IV Ignition element
V Augur motor
VI Circulation pump
VII Reserve
CONTROL MOTHER BOARD
1
2
3
4
5
6
7
8
9
VII VI
V
IV
III
II I
PE
N
L
a
b
PE gelb/grün, giallo/verde
A
BC
yellow/green
blue
brown
