Rinnai EX DT Series User Manual

EX17DT and EX22DT Installation and Operation Manual 9
Measurements: inches (mm)
3.3 Dimensions
A full size wall template is provided on the furnace carton box. Do not discard until installation is
complete.
IMPORTANT
Figure 3: Front View Figure 4: Side View
Side View
Front View (Including Sample Wall Template
Located on Furnace Carton Box)
Wall Bracket
Center of
Furnace
Wall
Opening
Position
Wall Opening Position
The hole center should be
within the shaded area.
Flue
Elbow
