Rinnai Corporation EX17 / EX22 Manual
Operating the Heater Manually
1
1
2
3
■ To turn the heater ON:
Press the “ON/OFF” button.
Check to see if the “Man” or “Auto”
indicator is displayed:
If the “Auto” indicator is displayed
then press the “Auto” button. The
indicator will change to “Man”.
Go to Step 3.
If the “Man” indicator is displayed
go to Step 3.
Select the desired room temperature
by pressing the “▲” or “▼” buttons.
The heater will start and run for 90 seconds so that it can check the room temperature
(the indicator will show).
If the room temperature is lower than the pre-set or desired temperature the heater will continue to run.
If the room temperature is higher than the pre-set or desired temperature, the heater will go into “stand-
by” mode, and will start when the room temperature falls below the pre-set temperature.
If the heater does not ignite on initial use, this may be due to air remaining in the gas supply line. The
spark generator will only continue for 15 seconds. After this it will be necessary to press the ON/OFF
button OFF, then ON again.
■ To turn the heater OFF:
Press the “ON/OFF” button.
DO NOT turn heater off by unplugging the power cord.
The convection fan will continue to run until the appliance cools.
ON/OFF
Set Room
Auto ON
pm
1
Tu
EcoFrost
Override
Auto ON/OFF
Set Room
Man
ON
pm
Tu
indicator
indicator
Set Room
Man
ON
pm
Tu
Programming
Clock Select
Timers
pm
Tu
EcoFrost
Override
Auto ON/OFF
