Rinnai V65e - Additional clearances - V75 i, V65 i

8 Value Series Manual
24"
V
Check on whether local codes supersede these clearances.
 Avoid terminaon locaons near a dryer vent.
 Avoid terminaon locaons near commercial
cooking exhaust.
 You must install a vent terminaon at least 12
inches from the ground
60"
V
V
(1.52 m)
between
terminals at
dierent levels
(0.61 m) to wall or parapet
(0.30 m) between
terminals at same
level
12"
V V
(1.52 m) vercally
between terminals
V
60"
V
Addional clearances - V75i, V65i
12"
12"
36"
INSIDE
CORNER
V V
(0.30 m ) to
an inside
corner
(0.30 m) between
terminals at same
level
Important consideraons for locang vent
terminaon under a sot (venlated or unvenlated
or eave vent; or to a deck or porch)
 Do not install vent terminaon under a sot vent
such that exhaust can enter the sot vent
 Install vent terminaon such that exhaust and
rising moisture will not collect under
eaves. Discoloraon to the exterior of the
building could occur if installed too close.
 Do not install the vent terminaon too close
under the sot where it could present
recirculaon of exhaust gases back into the
combuson air intake part of the terminaon
