Communications Manual
Rev 3.10
Softwa
re Vers
ions 3.xx
Page 36
003R-618-
310
11.
A
dvanced T
y
pe Handling (TYPE_M
ENU)
The
men
u
ite
ms
can
b
e
a
ccessed
from
th
e
COMM
p
ort.
Figure
9
illustra
tes
example
s
of
the me
nu levels.
Figure 9:
TYPE_MENU Example
35
37
Table of Contents
Table of Contents
2
Introduction
4
Intended Audience
4
Scope
4
The Manuals Set
5
Document Conventions
5
Connecting to the Instrument
6
Opto-LINK
6
Opto-LINK Activation
6
Opto-LINK Communications Settings
6
RS-232 Connection
7
RS-232 Communications Settings
7
Opto-LINK Vs RS-232
10
Getting Started
11
Using Viewer
11
COMM Protocol Summary
11
Reading Gross Weight as Literal Value
12
Read Gross Weight as Final Value
12
Setting Values
12
Remote Key Press
12
RS-232 Ring Network Enhancement
12
RS-232 Ring Network Example
13
Protocol Overview
14
COMM Message Structure
14
Address Field
15
Command Field
15
Register ID Field
16
Optional Parameters
16
Return Value
16
RS-232 Ring Network Enhancement
16
Error Handling
17
Register Types
18
Permissions
19
Register Access
19
Calibration and Configuration Counters
20
Register Operations and Properties
21
Register Operations
21
Common Properties
21
Type
21
Menu Text
21
Permission
22
Type Specific Properties
22
Rangemin, Rangemax
22
Final Value
23
Literal Value
23
Default Value
23
Execute
23
Read Items
24
Reading Status and Error Codes
25
Reg_System_Status
25
Reg_System_Error
26
Remote Key Interface
27
Operation
27
Key-Codes
27
Physical Codes
27
Example
28
Logical Keys
28
Execute Functions
29
Calibration
29
Span
30
Linearisation
31
Save Settings to EEPROM
31
Streaming
32
Basic Operation
32
Registers Available to Stream
32
Example
33
Printing
34
Basic Operation
34
Tokens Available for Printing
34
Examples of Operation
35
Advanced Type Handling (Type_Menu)
36
Appendix - Program Constants
37
Register Types
37
Commands
37
Error Codes
38
Register Identifiers
38
Key Codes
41
Decimal, Binary and Hexadecimal Conversion
42
Setup and Calibration Errors
43
Glossary Terms
44
List of Figures
44
List of Tables
44
Index
46
