8.2. Setup and Calibration Errors
Error Description Resolution
The instrument may be in
Safe Setup and an item
that needs Full Setup
has been selected for
editing.
Access Full Setup to edit the
item.
(ENTRY)
(DENIED)
When accessing setup,
more than three attempts
have been made with the
incorrect passcode.
Turn the instrument off. When
the instrument is turned back
on, enter the correct passcode
to access setup.
(LIN.PT)
(LO)
An attempt has been
made to place a linear-
isation point below zero.
Incorrect linearisation point
entered (must be between
zero and full scale).
(PT.TOO)
(CLOSE)
An attempt has been
made to place a
calibration point too close
to an existing calibration
point.
Re-enter the calibration point.
Points must be spaced by at
least 2% of full scale from
each other.
(RES)
(LO)
The scale build is
configured for less than
100 graduations.
Check the resolution (count-
by) and capacity settings.
(RES)
(HIGH)
The scale build is
configured for more
than 30,000 graduations.
Check the resolution (count-
by) and capacity settings.
(SPAN)
(LO)
The load cell signal
range (span) is too small
for these settings.
Incorrect span weight entered
(must be between zero and
full scale). Scale wiring
incorrect. Wrong load cell
capacity (too large). Wrong or
no calibration weight added to
scale.
(SPAN)
(HI)
The load cell signal
range (span) is
too large for these
settings.
Incorrect span weight entered
(must be between zero and
full scale). Scale wiring
incorrect. Load cell capacity
too small for application.
(ZERO)
(LO)
An attempt has been
made to calibrate zero
below -2mV/V.
Scale wiring incorrect.
(ZERO)
(HI)
An attempt has been
made to calibrate zero
above +2mV/V.
Remove all weight from scale.
Scale wiring incorrect.
