Controls and Features
3
Top View
High range/low range selector
For acceleration measurement, set the vibration frequency
range to "Lo" (10 Hz to 1000 Hz) or "Hi" (1 kHz to
15 kHz).
Acceleration/velocity/displacement selector
Select the measurement mode with this switch.
H i g h r a n g e / l o w r a n g e s e l e c t o r
A c c e l e r a t i o n / v e l o c i t y /
d i s p l a c e m e n t s e l e c t o r
